RACEMAX 2 ITALIA GRX Di2 2X12 DISCUS 45|40

by 3T

Regular price£8,763.00 Sale price

RACEMAX 2 ITALIA GRX Di2 2X12 DISCUS 45|40

by 3T

Regular price£8,763.00 Sale price
Select Size
Select Colour
Select Handlebar

3T Racemax² Italia

For gravel racers: the super-reliable Shimano GRX Di2 2x electronic groupset and wide 3T aero Discus 45|40 LTD carbon wheels get you to the finish line first.

Speed, integration, versatility and fun — elevated.

The 3T Racemax² Italia is the latest evolution of 3T’s race-focused gravel platform, handmade in Italy using 3T’s Jazz Carbon manufacturing process. Built for fast gravel, mixed surfaces and riders who want road-bike speed with real-world tyre clearance, every detail has been refined for efficiency, control and integration.

Compared with the previous generation, the Racemax² Italia brings updated geometry, increased tyre clearance, integrated downtube storage and a rear light built directly into the seatpost. The frame is aerodynamically optimised around real gravel tyre widths, with clearance up to 51 mm WAM in 1x setups and up to 48 mm WAM in 2x setups.

Key Features

  • Made in Italy using 3T Jazz Carbon construction
  • Race-focused aero gravel geometry
  • Tyre clearance up to 51 mm WAM with 1x drivetrains
  • Up to 48 mm WAM clearance with 2x drivetrains
  • Integrated downtube storage with Fidlock closure
  • Integrated rear light in the seatpost
  • CeramicSpeed SLT headset bearings
  • Fully internal cable routing with 3T MORE Integrale technology
  • UDH compatible
  • Electronic groupset compatible only
  • Aerodynamic updates delivering a claimed 1.5% gain over the previous generation

Why We Like It

The Racemax² Italia is built for riders who want a gravel bike that still feels fast, sharp and purposeful. It keeps the aerodynamic DNA of the original Racemax, but adds more clearance, cleaner integration and practical storage for modern gravel racing and fast all-road riding.

For riders looking for a premium Italian-made aero gravel bike with genuine race intent, the Racemax² Italia sits right at the sharp end of the category.



MADE IN ITALY, WITH JAZZ CARBON

The Racemax² Italia is produced in our Presezzo factory, starting from dry carbon fibre wound automatically using the filament winding technique, followed by resin application through Resin Transfer Moulding

This is what we call Jazz Carbon.


TIRE CLEARANCE – UP TO 51 mm WAM

Since the launch of the first Racemax in 2020, tire trends have shifted towards wider profiles.

The Racemax² Italia now accommodates tires with a real width of up to 51 mm (Width-as-Measured) with 1x setups and up to 48 mm with 2x configurations.

INTERNAL STORAGE AND INTEGRATED REAR LIGHT

The clean design is enhanced by two new integration features:

The downtube houses a storage compartment that shields tools and tubes from the elements, with a wide opening and a secure and stable Fidlock closure.

The seatpost now integrates a practical rear light, perfectly aligned with the frame’s design.

1.5% FASTER THAN THE PREVIOUS GENERATION

Despite a slightly wider frontal area due to tyre size, simulations show that the Racemax² Italia is even more aerodynamic, with a measurable gain of 1.5%.

This improvement comes from even cleaner lines and details, such as front caliper bolts shielded by a cover plate.


Designed only for electronic groupsets.

Specs

RACEMAX 2 ITALIA ~ FRAMESET

RACEMAX 2 ITALIA ~ GRX Di2 2X12 DISCUS 45|40

FRAME
Racemax2 ITALIA Integrale (UDH). Integrated storage with Fidlock closure system
FRAME MATERIAL
Jazz Carbon: 3T’s in-house filament-winding using a combination of high-strength/high-stiffness fibers, combined with RTM resin injection. Made in Italy
FORK
3T Fango RaceMax2 Integrale w/ compact crown
HEADSET
Ceramic Speed SLT 44/33 (36/45deg) I 52/42 (45/45deg)
THRU-AXLE
100x12 front - 142x12 rear
HANDLEBAR
3T Aeroghiaia Integrale LTD (S&M: 40cm - L&XL: 42cm)
BAR TAPE
3T Prendo Speed
STEM
3T More (K-Edge GPS mount included) - (S: 80mm - M:90mm - L: 100mm - XL: 110mm )
BOTTLE CAGE
3T Carbon front load water bottle cage
REAR DERAILLEUR
Shimano GRX Di2 RD-RX825 12s
FRONT DERAILLEUR
Shimano GRX Di2 FD-RX825 12s
SHIFT/BRAKE LEVERS
Shimano GRX Di2 ST-RX825 12s
BRAKES
Shimano GRX BR-RX820 w/ Shimano RT-CL800 160MM rotors
CRANKSET
Shimano GRX FC-RX820-2 12s 48/31( S&M: 170 mm - L&XL: 172,5 mm )
CASSETTE
Shimano Ultegra CS-R8101-12 11-34T
WHEELSET
3T Discus 45|40 LTD
TIRES
Schwalbe G-One RS 700×45
SEATPOST
3T Racemax/Racemax2 ITALIA seatpost for Ritchey clamp with integrated light system
SADDLE
Fizik Vento Argo R1 Light 140 mm

Geometries

Size S M L XL
Rider Height* (cm) 157-171 168-180 176-186 183-195
Rider Height* (inches) 5'2"-5'7" 5'6"-5'11" 5'9"-6'1" 6'0" 6'5"
01. Stack 547 569 589 609
02. Reach 367 377 385 393
03. Headtube angle 70.5 71.5 71.5 71.5
04. Fork axle-crown 383 383 383 383
05. Headtube length 138 152 173 197
06. BB drop 79 79 79 76
07. Seattube angle 74 74 74 74
08. Seattube length 463 491 510 537
09. Toptube length 522 538 552 566
10. Front center 609 607 622 636
11. Rear center 420 420 420 420
12. Wheelbase 1017 1015 1029 1045

*Rider heights are approximations. For more accuracy, compare stack/reach with your current bike or visit your 3T retailer.
