Quick-release rear rack
ORTLIEB Quick-Rack Pannier Rack
A quick-release aluminium rear rack that turns a sporty bike into a load-carrier in seconds, offered in three sizes to cover everything from road bikes to plus-tyred mountain bikes.
Highlights
Why we rate it
Seconds to swap
Clicks on in about fifteen seconds and off in five, so you only carry the rack when you need it.
Three sizes
Standard suits everyday and gravel bikes, L clears wider tyres, and XL takes plus tyres with a 26kg rating for MTB and e-bike use.
Two hanging levels plus platform
Run panniers and a top load or basket together without them fouling each other.
Broad bag compatibility
10mm struts (12mm on XL) work with all ORTLIEB mounting systems and many other brands' bags.
Fits bikes without eyelets
Use frame eyelets, the Seat Stay Adapter, or the Thru Axle M6-Connector recommended for L and XL.
Tech specs
Specification
Manufacturer specification. Details may change without notice.
Specification
- Weight
- 580g (Standard), 605g (L), 780g (XL)
- Max load
- 20kg (Standard, L), 26kg (XL)
- Material
- Aluminium
- Strut diameter
- 10mm (XL 12mm)
- Dimensions, Standard (H x W x D)
- 39 x 18.5 x 40 cm
- Tyre clearance, Standard
- 29in x 2.35in direct/seat stay; 28in x 30mm thru-axle
- Tyre clearance, L
- 29in x 3.0in direct/seat stay; 28in x 50mm thru-axle
- Tyre clearance, XL
- 29in x 3.0in direct/seat stay; 29in x 2.6in thru-axle
- Recommended mounting
- Standard: eyelets or Seat Stay Adapter; L and XL: Thru Axle M6-Connector
- Suited to
- Standard: city, touring, gravel, road, MTB; L: touring, gravel; XL: MTB, e-bike
- Mudguard
- Compatible with Quick-Rack Mudguard
Ordering
Available from The Cycle Collective
Available to order through The Cycle Collective in Dorking. For availability, fitting or advice, call 0203 148 6764 or email hello@thecyclecollective.cc.
