Quarq DFour DUB 110 BCD Road Power Meter Crankset
Quarq's carbon DUB road crankset with a 110 BCD power spider, made to take Shimano four-arm chainrings. Measures both legs to ±1.5%; chainrings and bottom bracket not included.
Highlights
Why we rate it
Shimano ring fit
The 110 BCD four-arm spider is shaped for Dura-Ace R9100 rings and also takes Ultegra R8000 and 105 R7000 rings.
Dual-leg spider
Measures combined power from both legs, with OmniCal so ring changes don't upset calibration.
Set-and-forget
MagicZero handles zeroing during rides and 10K temperature compensation keeps readings steady.
Carbon DUB arms
Carbon crank arms on a DUB spindle, for any SRAM road DUB bottom bracket.
Tech specs
Specification
Manufacturer specification. Details may change without notice.
Specification
- Power meter type
- Spider, dual-leg total power
- Claimed accuracy
- ±1.5%
- BCD
- 110 (4-arm)
- Chainring compatibility
- Shimano Dura-Ace R9100 (designed for); Ultegra R8000, 105 R7000
- Crank arms
- Carbon fibre
- Spindle / BB
- DUB; requires a SRAM road DUB bottom bracket
- Crank lengths
- 170, 172.5, 175mm
- Battery
- CR2032, up to 200 hours
- Connectivity
- ANT+ and Bluetooth; firmware via SRAM AXS app
- Calibration
- MagicZero auto-zero, OmniCal, 10K temperature compensation
- Water resistance
- IPX7
In the box
- Includes
- Carbon crank arms, DUB spindle, 110 BCD power meter spider (chainrings and bottom bracket not included)
